SKU: 3CX10,000A7


Call or email first to confirm stock prior to entering an order(info@newtube.com)



The 3CX10000A7  /  8160  /  3CX10,000A7 Vacuum tube is used in RF applications or audio amplifiers.


Electrical specifications for the 3CX10000A7  /  8160  /  3CX10,000A7 Vacuum tube:

Filament                                                    Thoriated tungsten mesh

Voltage                                                                           7.5 Volts

Current                                                                           99 Amps

Amplification factor                                                                  200

Plate Dissipation                                                       10,000 Watts

Grid Dissipation                                                              500 Watts

Maximum frequency for full rating CW                             160 MHz

Capacitance Grounded Cathode connection:

Input                                                                                     59 pF

Output                                                                                   .2 pF

Feedback                                                                              36 pF


Mechanical specifications for the 3CX10000A7  /  8160  /  3CX10,000A7 Vacuum tube:


Cooling                                                                         Forced Air

Base                                                                                  Coaxial

Length                                                                               8.75 in.

Diameter                                                                           7.05 in.

Weight                                                                                12 lbs.


Price: $1,995.00
