SKU: 3CX15,000A7


Call or email first to confirm stock prior to entering an order(info@newtube.com)



The 3C15000A7  /  3CX15,000A7 Vacuum tube is a high mu triode for use as zero bias class B RF amplifier.


Electrical specifications for the 3CX15000A7  /  3CX15,000A7 Vacuum tube.

Filament                                                  Thoriated Tungsten mesh

Voltage                                                                          6.3 Volts

Current                                                                        160 Amps

Amplification factor                                                               200

Plate Dissipation                                                      15,000 Watts

Grid Dissipation                                                            500 Watts

Maximum frequency for full rating CW                            110 MHz

Capacitance Grounded Cathode connection:

Input                                                                                     61 pF

Output                                                                                   .2 pF

Feedback                                                                             36 pF


 Mechanical specifications for the 3CX15000A7  /  3CX15,000A7 Vacuum tube:


Cooling                                                                       Forced Air

Base                                                                                Coaxial

Length                                                                               8.75 in.

Diameter                                                                           7.05 in.

Weight                                                                                12 lbs.


Price: $2,450.00
