3CX4500F3

Posted by tntadmin
$1,199.00
SKU: 3CX4500F3

3CX4500F3

Call or email first to confirm stock prior to entering an order(info@newtube.com)

The 3CX4500F3  /  YU108 Vacuum tube is a medium mu triode used in Industrial RF heating applications.

Electrical specifications for the 3CX4500F3  /  YU108 Vacuum tube:


Filament                                                Thoriated Tungsten mesh
Voltage                                                                            7 Volts
Current                                                                         78 Amps
Amplification factor                                                                 22
Plate Dissipation                                                       6,000 Watts
Grid Dissipation                                                           300 Watts
Maximum frequency for full rating CW                           75 MHZ
Capacitance Grounded cathode connection:
Input                                                                                   95 pf
Output                                                                                 .9 pf
Feedback                                                                           20 pf
Mechanical specifications for the 3CX4500F3  /  YU108 Vacuum tube:
Cooling                                                                      Forced Air
Base                                                                       Flexible leads
Length                                                                                  9 in.
Diameter                                                                          6.12 in.
Weight                                                                             9.5 lbs.

Typical Operation under load
Class of operation (C)
Plate Voltage                                                             9,000 Volts
Plate Current                                                                   3 Amps
Driving Power                                                              710 watts
Output Power                                                         14,000 watts
Price: $1,199.00
