3CX6000A7 NO STOCK 12 weeks leadtime , check back for stock notice

Posted by tntadmin
SKU: 3CX6000A7


Call or email first to confirm stock prior to entering an order(info@newtube.com)



The 3CX6000A7  /  YU148  /  YU 148  Vacuum tube is a power triode for use in zero bias RF amplifier or modulator service.
Electrical specifications for the 3CX6000A7  /  YU148  /  YU 148 Vacuum tube:

Filament                                                 Thoriated Tungsten mesh
Voltage                                                                             7 Volts
Current                                                                          78 Amps
Amplification factor                                                                200
Plate Dissipation                                                        6000 Watts
Grid Dissipation                                                           225 Watts
Maximum frequency for full rating CW                          110 MHz
Capacitance Grounded Cathode connection:
Input                                                                                    42 pF
Output                                                                                .28 pF
Feedback                                                                            24 pF
Mechanical specifications for the  3CX6000A7  /  YU148  /  YU 148 Vacuum tube:
Cooling                                                                       Forced Air
Base                                                                                Coaxial
Length                                                                                   9 in.
Diameter                                                                            6.1 in.
Weight                                                                                8 lbs.
Price: $1,495.00
