SKU: 4CX10,000J


Call or email first to confirm stock prior to entering an order(info@newtube.com)






Electrical specifications for the 4CX10000J  /  4CX10,000J Vacuum tube:

Filament                                                 Thoriated Tungsten mesh

Voltage                                                                         7.5 Volts

Current                                                                      103  Amps

Amplification factor                                                                4.5

Plate Dissipation                                                     12,000 Watts

Grid Dissipation                                                             75 Watts

Maximum frequency for full rating CW                          100 MHz

Capacitance Grounded cathode connection:

Input                                                                                  120 pF

Output                                                                              20.5 pF

Feedback                                                                             .7 pF


Mechanical specifications for the 4CX10000J  /  4CX10,000J Vacuum tube:


Cooling                                                                       Forced Air

Base                                                                                Coaxial

Length                                                                              9.12 in.

Diameter                                                                            7.0 in.

Weight                                                                           12.2 lbs.



Price: $2,050.00
