4CX5000A

Posted by tntadmin
$1,265.00
SKU: 4CX5000A

4CX5000A

Call or email first to confirm stock prior to entering an order(info@newtube.com)











The 4CX5000A  /  8170  /  RS2014CL  Vacuum tube is used as an Oscillator, Modulator or Amplifier at frequencies up to 220 MHz.



Electrical specifications for the 4CX5000A  /  8170  /  RS2014CL  Vacuum tube:


Filament                                                  Thoriated Tungsten mesh

Voltage                                                                          7.5 Volts

Current                                                                          75 Amps

Amplification factor                                                                 4.5

Plate Dissipation                                                         6000 Watts

Grid Dissipation                                                              75 Watts

Maximum frequency for full rating CW                           220 MHz

Capacitance Grounded Cathode connection:

Input                                                                                  120 pF

Output                                                                               20.5 pF

Feedback                                                                              .7 pF



Mechanical specifications for the 4CX5000A  /  8170  /  RS2014CL  Vacuum tube:



Cooling                                                                        Forced Air

Base                                                                                 Coaxial

Length                                                                              9.13 in.

Diameter                                                                           4.94 in.

Weight                                                                               9.5 in.




Price: $1,265.00
