4CX5000R

Posted by tntadmin
$1,295.00
SKU: 4CX5000R



4CX5000R

Call or email first to confirm stock prior to entering an order(info@newtube.com)







The 4CX5000R  /  8170W  Vacuum tube is used as a RF linear amplifier and class AB Audio amplifier.



Electrical specifications for the 4CX5000A  /  8170W  Vacuum tube:



Filament                                                Thoriated Tungsten mesh

Voltage                                                                         7.5 Volts

Current                                                                         75 Amps

Amplification factor                                                                4.5

Plate Dissipation                                                       5000 Watts

Grid Dissipation                                                            75 Watts

Maximum frequency for full rating CW                          100 MHz

Capacitance Grounded Cathode connection:

Input                                                                                 115 pF

Output                                                                             20.5 pF

Feedback                                                                            .7 pF



Mechanical specifications for the 4CX5000R  /  8170W  Vacuum tube:



Cooling                                                                      Forced Air

Base                                                                               Coaxial

Length                                                                             9.13 in.

Diameter                                                                         4.94 in.

Weight                                                                            9.5 lbs.



Price: $1,295.00
