3CX1500A7

Posted by tntadmin
$895.00
SKU: 3CX1500A7

3CX1500A7

Call or email first to confirm stock prior to entering an order(info@newtube.com) this product is made in China.

The 3CX1500A7  /  8877  Vacuum tube is high mu  triode.

Electrical specifications for the 3CX1500A7  /  8877  Vacuum tube :

Filament                                                                  Oxide Coated

Voltage                                                                              5 Volts

Current                                                                        10.5 Amps

Amplification factor                                                                 200

Plate Dissipation                                                          1500 Watts

Grid Dissipation                                                              25 Watts

Maximum frequency for full rating CW                           250 MHz



Mechanical specifications for the 3CX1500A7  /  8877 Vacuum tube:

Cooling                                                                        Forced Air

Base                                                                                      7 pin

Length                                                                               4.02 in.

Diameter                                                                           3.38 in.

Weight                                                                               1.6 lbs.



Price: $895.00
