JD102CRC Jolida Integrated Amp,

Posted by fgxadmin
$785.00
SKU: JD102CRC

 With a circuit design based on early 1960s American tube amplifiers, the Jolida 102CRC is a blast from the past. Small in stature, but not in performance, the JD102CRC has a big heart, delivering a surprising amount of juice even into difficult loads. With four inputs and both a 4Ohm and 8Ohm tap, the JD102B is quite flexible. We've used the JD102CRC on efficient tower speakers, inefficient bookshelf speakers and everything in between with great results. The elegant understated appearance works well with virtually any system and the small form factor makes the JD102CRC a great alternative to solid state or digital mini amps. Besides, the golden glow of those seven tubes will warm your heart, but not your room!

 Sales Policy : All sales are final no returns accepted.If any Jolida shipment is refused and or returned for any reason including a possible defect and no defect is found a 25% restocking fee will be imposed addditionaly  customer will be responsible for all shipping charges to and from the shipping point.By placing an order you are accepting these terms.Free shipping applies to Domestic U. S. Locations Only





Maximum power Output: 25 W per channel at 8 ohms,  1KHz

Rated Output Power:                    20 W per channel at 8 ohms, 26Hz to 50KHz

Frequency Response:                  (at 1 watt into 8 ohms) 7Hz to 95KHz + 1dB; 0dB at 1KHz

Bandwidth:                                      14Hz to 80KHz + 3dB; 0dB = 20 W 1KHz, 8 ohms

Distortion THD + N:                       Less than 1.5% at 15W output, 39Hz to 10KHz, 8 ohms

Circuit Type:                                    Ultra Linear, Class AB1

Input Impedance:                           = or < 250Kohms

Input Sensitivity:                            Max. 900mV for 20 watt output at 1KHz

Output Impedance:                        4 ohms and 8 ohms

Negative Feedback:                      Less than 7 dB

Signal & Noise Ratio S/N:            70dB below rated output from 10Hz to 200Khz   .

Tube Complement:                        4 pieces EL84 power output tubes; 2 pcs. 12AT7A  driver tubes, 12AX7 pre-amplifier tubes.

Power Requirements:                   110V-120 VAC 60Hz 90 watts-standby, (220-240 VAC 50Hz option.

Bias Settings:                                  20 millivolts +/- 2 millivolts

Dimensions:                                    12 inches wide by 8 inches deep by 5 inches high.

Weight:                                              27 pounds net, approximately 31 pounds packaged.

Fuse:                                                 For 110/120 VAC: 6.3 amp slow blo, for 220/240 VAC: 3.15 amp slow blo, Size: 5mm X 20mm

Warranty:                                          One year limited parts and labor.

Construction Details and Features:

o Fully Integrated Stereo Amplifier: Input 900mV driving 20 watts, maximum 25 watts output.

o Multiple Inputs: CD and Aux (for Tuner, TV, VCR, Tape Recorder, Computer and etc).  Fixed     and Variable out are available on request.

o Right and Left Stereo Balance Control: + 20dB at both right and left front panel control.

o Custom Wound Audio Transformers with a core of German grain oriented silicon steel. 15th generation proprietary design.  Secondary can be configured for a 4 ohm or 8 ohm load.

o Top Panel Bias Testing Terminals with Bias Adjustment Controls.

o State of the Art Components: Alps potentiometer, Gold plated RCA input jacks, gold plated five way speaker connectors.

o Comes in Black or Silver








Price: $785.00
